Safety sign warning about power line clearance requirements and electrocution hazard.

Crane Power Line Clearance Requirements Sticker

EC-003

$5.75 USD

Crane Power Line Clearance Requirements Safety Decal Printed with,

DANGER Electrical Hazard Overhead Power Line Clearance Requirements.

20' of clearance is required for power lines up to 350 kV or 50' of clearance for power lines that exceed 350 kV. If any part of the equipment, load line, or load could get in the prohibited zone while operating up to the crane's maximum radius, then the employer can choose the following:
• Line verified de-energized & visibly grounded by utility owner.
• Clearance: maintain clearance from a prohibited zone: with additional encroachment prevention measures as defined in 1926.1407,.1408, and .1409.
• Determine lines voltage and minimum approach distance permitted under Table A* with additional encroachment prevention measures as defined in 1926.1407,.1408, and .1409

TABLE A - Minimum Clearance Distances While in Operation

Crane Power Line Clearance Requirements Sticker size is 10 inches wide by 5 1/2 inches tall.

Safety Labels make it easy to put important reminders in the necessary places. Safety comes first! Our safety labels come in various sizes, are cost-effective, and are laminated for durability from grease, oil, and every day wear & tear.

Our labels meet OSHA standards for safety protocol and compliance.  Our labels are created from durable materials, are impactful & serve as critical reminders of safe workplace tactics.

Our Crane Power Line Clearance Requirements Sticker is created, printed, cut, and shipped in the USA.

Technical & Safety Data

Product Composition & Identification

Film Construction: 2.75 mil Polymeric Calendered Vinyl base paired with a 2.75 mil flexible clear Polymeric Calendered Vinyl overlaminate.

Adhesive System: Clear Solvent-Based Permanent Pressure Sensitive Acrylic.

Total Adhesive Thickness: 2.3 mil combined (1.2 mil base and 1.1 mil laminate).

Health, Safety & Regulatory Compliance

Fire Rating: Class A fire rating under ASTM E84-17 testing.

Commercial Safety: Meets the highest life safety requirements for indoor and outdoor commercial graphics.

Toxicity & Structure: Phthalate-Free Film Structure.

Regulatory Standards: Meets the health and safety requirements set forth by CPSIA, REACH, RoHS, and California Proposition 65.

Physical & Chemical Properties

Chemical Resistance: Resists mild acids, mild alkalis, solvents, and salts.

Moisture Resistance: Excellent resistance to water, including full immersion.

Tensile Strength: 12.5 Pounds/Inch.

Dimensional Stability: 0.020 Inch (Machine Direction).

Peel Adhesion: 4.5 Pounds/Inch from Stainless Steel.

Environmental & Temperature Tolerances

Operating Temperature Range: -40°F to 190°F.

Application Temperature: 50°F to 80°F recommended.

Installation Surface: Clean, dry, and free of dust, dirt, debris, or grease.

Outdoor Lifespan: Up to 5 years permanent durability.
