Horizontal crane warning sticker with red DANGER header, KEEP CLEAR OF SWINGING UPPER wording, a crushing-person illustration and CRUSHING HAZARD caption.
Vertical crane warning sticker with red DANGER header, a crushing-person illustration and wording to keep clear of the swinging upper.

Crane Swinging Upper Crush Hazard Sticker – Horizontal or Vertical

CSr-004

$5.75 USD

This non-OEM crane rotation warning sticker warns people to keep clear of the swinging upper. Choose a horizontal or vertical layout to match the replacement warning and mounting space on your rough-terrain crane.

Both designs have a red DANGER header and an illustration of a person being crushed between moving and fixed surfaces.

Printed warning

DANGER

KEEP CLEAR OF SWINGING UPPER TO PREVENT SERIOUS BODILY INJURY

The horizontal design also prints:

CRUSHING HAZARD

The vertical design carries the same keep-clear warning but does not include the separate “CRUSHING HAZARD” caption.

Choose the layout and size

Horizontal, CSr-004: 10 inches wide × 5 inches tall. The warning text appears on the left, with the illustration and CRUSHING HAZARD caption on the right.

Vertical, CSr-004V: 4¼ inches wide × 8¾ inches tall. The illustration appears beneath the DANGER header, with the warning text below it.

Compare the complete wording, artwork, dimensions and orientation with the label specified for your equipment. These are non-OEM replacement decals, not a claim of universal fit across rough-terrain crane models.

Placement for approaching personnel

Follow the equipment manufacturer’s decal map and preserve the original location when replacing a matching warning.

As general guidance, use a visible, fixed exterior panel facing the relevant approach to the rotating upper or counterweight area. People should be able to read the warning before entering the hazard area; a cab-only label may not communicate the message to those approaching from the ground.

These are general recommendations, not verified factory locations for a particular crane. Do not enter a swing or crush area to install the decal. Apply to a suitable clean, dry surface without covering controls, identification, load charts or other warnings.

Warning decal, not a protective barrier

This sticker communicates the printed warning. It does not restrict rotation, establish a safe clearance distance or replace barriers, manufacturer instructions and site procedures.

For help matching a replacement or discussing a different size, contact Crane Safety Stickers or call 419-677-5035.

Technical & Safety Data

Product Composition & Identification

Film Construction: 2.75 mil Polymeric Calendered Vinyl base paired with a 2.75 mil flexible clear Polymeric Calendered Vinyl overlaminate.

Adhesive System: Clear Solvent-Based Permanent Pressure Sensitive Acrylic.

Total Adhesive Thickness: 2.3 mil combined (1.2 mil base and 1.1 mil laminate).

Health, Safety & Regulatory Compliance

Fire Rating: Class A fire rating under ASTM E84-17 testing.

Commercial Safety: Meets the highest life safety requirements for indoor and outdoor commercial graphics.

Toxicity & Structure: Phthalate-Free Film Structure.

Regulatory Standards: Meets the health and safety requirements set forth by CPSIA, REACH, RoHS, and California Proposition 65.

Physical & Chemical Properties

Chemical Resistance: Resists mild acids, mild alkalis, solvents, and salts.

Moisture Resistance: Excellent resistance to water, including full immersion.

Tensile Strength: 12.5 Pounds/Inch.

Dimensional Stability: 0.020 Inch (Machine Direction).

Peel Adhesion: 4.5 Pounds/Inch from Stainless Steel.

Environmental & Temperature Tolerances

Operating Temperature Range: -40°F to 190°F.

Application Temperature: 50°F to 80°F recommended.

Installation Surface: Clean, dry, and free of dust, dirt, debris, or grease.

Outdoor Lifespan: Up to 5 years permanent durability.
