Technical & Safety Data
Product Composition & Identification
Film Construction: 2.75 mil Polymeric Calendered Vinyl base paired with a 2.75 mil flexible clear Polymeric Calendered Vinyl overlaminate.
Adhesive System: Clear Solvent-Based Permanent Pressure Sensitive Acrylic.
Total Adhesive Thickness: 2.3 mil combined (1.2 mil base and 1.1 mil laminate).
Health, Safety & Regulatory Compliance
Fire Rating: Class A fire rating under ASTM E84-17 testing.
Commercial Safety: Meets the highest life safety requirements for indoor and outdoor commercial graphics.
Toxicity & Structure: Phthalate-Free Film Structure.
Regulatory Standards: Meets the health and safety requirements set forth by CPSIA, REACH, RoHS, and California Proposition 65.
Physical & Chemical Properties
Chemical Resistance: Resists mild acids, mild alkalis, solvents, and salts.
Moisture Resistance: Excellent resistance to water, including full immersion.
Tensile Strength: 12.5 Pounds/Inch.
Dimensional Stability: 0.020 Inch (Machine Direction).
Peel Adhesion: 4.5 Pounds/Inch from Stainless Steel.
Environmental & Temperature Tolerances
Operating Temperature Range: -40°F to 190°F.
Application Temperature: 50°F to 80°F recommended.
Installation Surface: Clean, dry, and free of dust, dirt, debris, or grease.
Outdoor Lifespan: Up to 5 years permanent durability.
