The stock-size chart measures 6 inches wide × 12 inches tall. The 5-inch-wide × 9-inch-tall version is made per order. Both show the same 20 illustrated signals.
H-001
This mobile crane hand signal chart decal displays 20 illustrated hand signals in a black-and-white layout with English captions. It provides a visual reference for crane operators and signal persons, including hoist, lower, swing, stop, emergency stop and boom movements. Choose the size that fits your intended display location.
Both sizes show the same 20 signals. Select the required size before adding to your cart. The 5 × 9-inch version is made to order; turnaround is usually 1-2 business days.
Use the chart as a supplemental visual reference, not as a substitute for signal-person training, qualification, agreed communication procedures or equipment instructions. Match the signals used to the crane, operation and applicable requirements. The chart itself does not certify compliance or guarantee accident prevention.
Choose a readable display location appropriate to the equipment and work area, following manufacturer and site instructions. Do not cover controls, rating plates or existing warnings.
Read our guide to the 20 common mobile crane hand signals for explanations of the signals illustrated on this chart.
