How to Signal a Crane Operator Using Crane Hand Signals

Crane hand signals communicate specific movements between a signal person and a crane operator. This illustrated guide explains 20 mobile crane hand signals, including stop signals, boom movements, hoisting, crawler travel, and hoist selection.

These examples are not a complete signal set for every crane or a qualification course. Match the signaling method to the equipment and operation, and use the applicable equipment instructions and site procedures. See the official references and qualification guidance below, including the separate source for one-handed telescoping-boom signals.

In this guide

Stop and hold signals

1. Emergency stop

Extend both arms horizontally to the sides, with palms down, and swing both arms back and forth.

Emergency Stop Hand Signal for Crane Operator

2. Stop

Extend one arm horizontally to the side, with the palm down, and swing the arm back and forth.

Stop Crane Hand Signal For Crane Operator

3. Dog everything

Hold both hands together at waist level.

Keep this gesture distinct from the stop and emergency-stop gestures. The illustrations show different signals, not interchangeable ways to perform the same hand movement.

Dog Everything Hand Signal For Crane Operator

Boom movement signals

4. Raise boom

Extend one arm horizontally to the side. Point the thumb up with the other fingers closed.

This signals boom movement, not simply raising the load with the hoist.

Raise Boom Hand Signal For Crane Operators

5. Lower boom

Extend one arm horizontally to the side. Point the thumb down with the other fingers closed.

Lower Boom Hand Signal For Crane Operators

6. Swing

Extend one arm horizontally and point the index finger in the direction the boom is to swing.

Swing Boom Hand Signal For Crane Operators

7. Extend telescoping boom

Hold both hands in front of the body at waist level, with the thumbs pointing outward and the other fingers closed.

This is a telescoping-boom signal. Do not assume every crane has a boom that extends and retracts.

Extend Boom Hand Signal For Crane Operators

8. Retract telescoping boom

Hold both hands in front of the body at waist level, with the thumbs pointing toward each other and the other fingers closed.

Retract Boom Hand Signal For Crane Operators

Hoisting and lowering signals

9. Hoist

Extend the upper arm to the side, with the forearm and index finger pointing straight up. Make small circles with the hand and finger.

Notice the bent elbow in the illustration. This is different from reaching the entire arm straight overhead.

Hoist Load Hand Signal For Crane Operators

10. Lower

Point the arm and index finger down, and make small circles with the hand and finger.

Keep the hoist and lower signals distinct from raise-boom and lower-boom signals: they communicate different equipment movements.

Lower Load Hand Signal For Crane Operators

Controlling movement speed

11. Move slowly

Place one hand in front of the hand giving the action signal.

The illustration shows a hoist-slowly example. The extra hand modifies the action signal; it does not replace it.

Move Slowly, Hoist Slowly Hand Signal For Crane Operators

Crane travel signals

12. Travel

With all fingers pointing upward, extend the arm horizontally and move it out and back in a pushing motion toward the intended direction of travel. This signals crane travel, not boom swing.

Crane travel hand signal showing an upright open hand and pushing-motion arrow.

13. Travel — both tracks

For crawler-crane travel, rotate both fists around each other in front of the body. Rotation away from the body indicates forward travel; rotation toward the body indicates backward travel.

Crawler crane both-tracks travel signal showing two fists in front of the body with rotation arrows.

14. Travel — one track

Raise a fist to identify the track that is to remain locked. Rotate the other fist vertically in front of the body to indicate the direction the opposite track should travel. This signal applies to tracked-crane movement.

Crawler crane one-track travel signal showing one raised fist and the other fist in front of the body.

Selecting the hoist

15. Use main hoist

Tap the top of the head with one hand. Then give the regular action signal to indicate the desired movement. The head tap selects the main hoist; it does not, by itself, signal hoisting upward.

Use main hoist hand signal showing a hand tapping the top of the head.

16. Use auxiliary hoist — whipline

Bend one arm at the elbow with the forearm vertical, and tap that elbow with the other hand. Then give the regular action signal to indicate the desired movement.

Use whipline or auxiliary hoist signal showing one hand tapping the elbow of a raised forearm.

One-handed telescoping-boom signals

The following one-handed signals are illustrated in the Washington State Labor & Industries reference linked in the references section below. Use the signaling method applicable to the equipment and operation.

17. Extend telescoping boom — one hand

Hold one fist in front of the chest with the thumb tapping the chest.

One-handed extend-boom signal showing a fist at the chest while the other hand holds a line.

18. Retract telescoping boom — one hand

Hold one fist in front of the chest, with the thumb pointing outward and the heel of the fist tapping the chest.

One-handed retract-boom signal showing a fist at the chest with the thumb pointing outward.

Combined boom and load movements

19. Raise the boom and lower the load

Extend one arm horizontally to the side with the thumb pointing upward. Open and close the fingers while load movement is desired. This combines boom raising with load lowering.

Raise the boom and lower the load signal with an extended arm, thumb up, and a hand-position inset.

20. Lower the boom and raise the load

Extend one arm horizontally to the side with the thumb pointing downward. Open and close the fingers while load movement is desired. This combines boom lowering with load raising.

Lower the boom and raise the load signal with an extended arm, thumb down, and a hand-position inset.

Standard hand signals and signal-person qualifications

For operations covered by OSHA’s construction crane standard, 1926.1419 requires the Standard Method when hand signals are used, subject to the exceptions described in that section. The illustrated reference is Appendix A to Subpart CC.

This guide also references Washington State Labor & Industries’ Standard Hand Signals for Cranes, which illustrates the one-handed telescoping-boom signals described above. Do not treat every illustration here as a separate signal shown in OSHA’s Appendix A.

Knowing the illustrations is only part of signal-person qualification. Under 1926.1428, qualification includes understanding and applying the signals, understanding relevant equipment operation and limitations, and demonstrating knowledge through an oral or written test and a practical test.

The rule provides evaluation options through a third-party qualified evaluator or an employer’s qualified evaluator. Reading this guide or purchasing a chart does not qualify someone to act as a signal person.

Choosing a crane hand signal chart

Choose a chart that matches the signal system used for the crane and operation. Mobile-crane, overhead-crane, and banksman charts should not be treated as interchangeable.

Compare the illustrations, captions, language, dimensions, and intended mounting space before ordering. Position the chart without obstructing controls, the operator’s view, identification plates, or existing warnings.

Browse our Crane Hand Signal Charts – Mobile & Overhead to compare available formats. For a mobile-crane reference you can print yourself, see our Free Crane Hand Signals Poster. The free option is a PDF, not a physical poster shipped to you.

For posting-location guidance, read Where to Post Crane Hand Signal Charts on Your Job Site.

A chart is a reference aid. It does not replace signal-person qualification, equipment instructions, or agreed communication procedures, and displaying one does not by itself establish compliance.
