Design Your Own Custom Safety Sticker | Choose Size & Layout

CUST-16-5x3.5

Create a custom safety sticker using a layout, wording, and images you choose. Select your sticker size and starting design, then personalize it in the online designer before ordering.

Choose your size and starting layout

Available sticker sizes are 5 × 3.5, 7 × 5, 10 × 7, 14 × 10, and 18 × 12 inches. In the designer, open Variants to select a size and browse starting header layouts. The first product image shows one example of a finished custom design; other images show blank layouts and size references.

Make the design your own

  1. Choose a size and starting layout.
  2. Add your wording with Add text. You can also use Upload for your own image, or Choose a pre-made design or browse the clipart and image library in the designer.
  3. Use Preview to check the finished layout, spelling, image placement, and selected size before you order.

The designer also displays AI Images and an Add Note option. Review all selections before choosing Order Now.

Creating a safety message? The wording, symbols, colors, and placement you choose should be checked against the requirements that apply to your equipment and workplace. A blank layout or finished custom sticker does not by itself establish regulatory compliance.

5 × 3.5, 7 × 5, 10 × 7, 14 × 10, and 18 × 12 inches. Contact us if you need a different size.

Yes, the designer has an Upload option; shoppers can also add text and choose from pre-made designs and clipart.

Yes, use Preview to review the design and selected size before choosing Order Now.

No. Buyers need to check the wording, symbols, colors, and placement against the requirements for their equipment and workplace.

Technical & Safety Data

Product Composition & Identification

Film Construction: 2.75 mil Polymeric Calendered Vinyl base paired with a 2.75 mil flexible clear Polymeric Calendered Vinyl overlaminate.

Adhesive System: Clear Solvent-Based Permanent Pressure Sensitive Acrylic.

Total Adhesive Thickness: 2.3 mil combined (1.2 mil base and 1.1 mil laminate).

Health, Safety & Regulatory Compliance

Fire Rating: Class A fire rating under ASTM E84-17 testing.

Commercial Safety: Meets the highest life safety requirements for indoor and outdoor commercial graphics.

Toxicity & Structure: Phthalate-Free Film Structure.

Regulatory Standards: Meets the health and safety requirements set forth by CPSIA, REACH, RoHS, and California Proposition 65.

Physical & Chemical Properties

Chemical Resistance: Resists mild acids, mild alkalis, solvents, and salts.

Moisture Resistance: Excellent resistance to water, including full immersion.

Tensile Strength: 12.5 Pounds/Inch.

Dimensional Stability: 0.020 Inch (Machine Direction).

Peel Adhesion: 4.5 Pounds/Inch from Stainless Steel.

Environmental & Temperature Tolerances

Operating Temperature Range: -40°F to 190°F.

Application Temperature: 50°F to 80°F recommended.

Installation Surface: Clean, dry, and free of dust, dirt, debris, or grease.

Outdoor Lifespan: Up to 5 years permanent durability.
